#include <MAVAddress.hpp>

Collaboration diagram for MAVAddress:

Public Member Functions
	MAVAddress (const MAVAddress &other)=default

	MAVAddress (MAVAddress &&other)=default

	MAVAddress (unsigned int address)

	MAVAddress (unsigned int system, unsigned int component)

	MAVAddress (std::string address)

unsigned int	address () const

unsigned int	system () const

unsigned int	component () const

MAVAddress &	operator= (const MAVAddress &other)=default

MAVAddress &	operator= (MAVAddress &&other)=default

Related Functions
(Note that these are not member functions.)
bool	operator== (const MAVAddress &lhs, const MAVAddress &rhs)

bool	operator!= (const MAVAddress &lhs, const MAVAddress &rhs)

bool	operator< (const MAVAddress &lhs, const MAVAddress &rhs)

bool	operator> (const MAVAddress &lhs, const MAVAddress &rhs)

bool	operator<= (const MAVAddress &lhs, const MAVAddress &rhs)

bool	operator>= (const MAVAddress &lhs, const MAVAddress &rhs)

std::ostream &	operator<< (std::ostream &os, const MAVAddress &mavaddress)

Detailed Description

A MAVLink address.

MAVLink addresses consist of a system and component and can be represented as two ocetets in the form:

system.component

Therefore, a system ID of 16 and a component ID of 8 can be represented as 16.8.

0.0 is reserved as the broadcast address.

Definition at line 38 of file MAVAddress.hpp.

Constructor & Destructor Documentation

◆ MAVAddress() [1/5]

MAVAddress::MAVAddress ( const MAVAddress & other )

default

Copy constructor.

Parameters

other MAVLink address to copy from.

◆ MAVAddress() [2/5]

MAVAddress::MAVAddress ( MAVAddress && other )

default

Move constructor.

Parameters

other MAVLink address to move from.

◆ MAVAddress() [3/5]

MAVAddress::MAVAddress ( unsigned int address )

Construct a MAVLink address from an address in numeric representation.

The numeric representation of a MAVLink address is two bytes, the MSB contains the system ID and the LSB contains the component ID.

Parameters

address Address (0 - 65535) with system ID encoded in MSB and component ID encoded in LSB.

Exceptions

std::out_of_range if the address is not between 0 and 65535.

Definition at line 38 of file MAVAddress.cpp.

References address().

Here is the call graph for this function:

◆ MAVAddress() [4/5]

MAVAddress::MAVAddress	(	unsigned int	system,
		unsigned int	component
	)

Construct a MAVLink address from the system ID and component ID.

Note: component=0 and system=0 is the broadcast address.

Parameters

system	System ID (0 - 255).
component	Component ID (0 - 255).

Exceptions

std::out_of_range if either the system ID or the component ID is out of range.

Definition at line 87 of file MAVAddress.cpp.

References component(), and system().

Here is the call graph for this function:

◆ MAVAddress() [5/5]

MAVAddress::MAVAddress ( std::string address )

Construct MAVLink address from a string.

Parse a string of the form "<System ID>.<Component ID>".

Some examples are:

"0.0"
"16.8"
"128.4"

Parameters

address String representing the MAVLink address.

Exceptions

std::invalid_argument	if the address string does not represent a valid MAVLink address.
std::out_of_range	if either the `system` ID or the `component` ID is out of range.

Definition at line 108 of file MAVAddress.cpp.

References address().

Here is the call graph for this function:

Member Function Documentation

◆ address()

unsigned int MAVAddress::address ( ) const

Return the MAVLink address in numeric form.

Returns: The MAVLink address as a two byte number with the system ID encoded in the MSB and the component ID in the LSB.

Definition at line 151 of file MAVAddress.cpp.

Here is the caller graph for this function:

◆ component()

unsigned int MAVAddress::component ( ) const

Return the Component ID.

Returns: The component ID (0 - 255).

Definition at line 171 of file MAVAddress.cpp.

Here is the caller graph for this function:

◆ operator=() [1/2]

MAVAddress& MAVAddress::operator= ( const MAVAddress & other )

default

Assignment operator.

Parameters

other MAVLink address to copy from.

◆ operator=() [2/2]

MAVAddress& MAVAddress::operator= ( MAVAddress && other )

default

Assignment operator (by move semantics).

Parameters

other MAVLink address to move from.

◆ system()

unsigned int MAVAddress::system ( ) const

Return the System ID.

Returns: The system ID (0 - 255).

Definition at line 161 of file MAVAddress.cpp.

Here is the caller graph for this function:

Friends And Related Function Documentation

◆ operator!=()

bool operator!=	(	const MAVAddress &	lhs,
		const MAVAddress &	rhs
	)

Parameters

lhs	The left hand side MAVLink address.
rhs	The right hand side MAVLink address.

Return values

true	if `lhs` and `rhs` do not have the same system and component ID's
false	if `lhs` and `rhs` have the same system and component ID's.

Definition at line 201 of file MAVAddress.cpp.

References address().

Here is the call graph for this function:

◆ operator<()

bool operator<	(	const MAVAddress &	lhs,
		const MAVAddress &	rhs
	)

Note: The System ID is considered first followed by the Component ID.

Parameters

lhs	The left hand side MAVLink address.
rhs	The right hand side MAVLink address.

Return values

true	if `lhs` is less than `rhs`.
false	if `lhs` is not less than `rhs`.

Definition at line 217 of file MAVAddress.cpp.

References address().

Here is the call graph for this function:

◆ operator<<()

std::ostream & operator<<	(	std::ostream &	os,
		const MAVAddress &	mavaddress
	)

The format is "<System ID>.<Component ID>".

Some examples are:

0.0
16.8
128.4

Note: The string constructor MAVAddress(std::string) and the output stream operator are inverses and thus:
std::string addr = "192.168"
str(MAVAddress(addr)) == addr

Parameters

os	The output stream to print to.
mavaddress	The MAVLink address to print.

Returns: The output stream.

Definition at line 292 of file MAVAddress.cpp.

References component(), and system().

Here is the call graph for this function:

◆ operator<=()

bool operator<=	(	const MAVAddress &	lhs,
		const MAVAddress &	rhs
	)

Note: The System ID is considered first followed by the Component ID.

Parameters

lhs	The left hand side IP address.
rhs	The right hand side IP address.

Return values

true	if `lhs` is less than or eqaul to `rhs`.
false	if `lhs` is greater than `rhs`.

Definition at line 249 of file MAVAddress.cpp.

References address().

Here is the call graph for this function:

◆ operator==()

bool operator==	(	const MAVAddress &	lhs,
		const MAVAddress &	rhs
	)

Parameters

lhs	The left hand side MAVLink address.
rhs	The right hand side MAVLink address.

Return values

true	if `lhs` and `rhs` have the same system and component ID's.
false	if `lhs` and `rhs` do not have the same system and component ID's.

Definition at line 186 of file MAVAddress.cpp.

References address().

Here is the call graph for this function:

◆ operator>()

bool operator>	(	const MAVAddress &	lhs,
		const MAVAddress &	rhs
	)

Note: The System ID is considered first followed by the Component ID.

Parameters

lhs	The left hand side MAVLink address.
rhs	The right hand side IP address.

Return values

true	if `lhs` is greater than `rhs`.
false	if `lhs` is not greater than `rhs`.

Definition at line 233 of file MAVAddress.cpp.

References address().

Here is the call graph for this function:

◆ operator>=()

bool operator>=	(	const MAVAddress &	lhs,
		const MAVAddress &	rhs
	)

Note: The System ID is considered first followed by the Component ID.

Parameters

lhs	The left hand side IP address.
rhs	The right hand side IP address.

Return values

true	if `lhs` is greater than or equal to `rhs`.
false	if `lhs` is less than `rhs`.

Definition at line 265 of file MAVAddress.cpp.

References address().

Here is the call graph for this function:

The documentation for this class was generated from the following files:
