UnixUDPSocket Class Reference

#include <UnixUDPSocket.hpp>

Inheritance diagram for UnixUDPSocket:

Collaboration diagram for UnixUDPSocket:

Public Member Functions
	UnixUDPSocket (unsigned int port, std::optional< IPAddress > address={}, unsigned long max_bitrate=0, std::unique_ptr< UnixSyscalls > syscalls=std::make_unique< UnixSyscalls >())
virtual	~UnixUDPSocket ()
virtual void	send (const std::vector< uint8_t > &data, const IPAddress &address) final
virtual std::pair< std::vector< uint8_t >, IPAddress >	receive (const std::chrono::nanoseconds &timeout=std::chrono::nanoseconds::zero()) final
virtual void	send (std::vector< uint8_t >::const_iterator first, std::vector< uint8_t >::const_iterator last, const IPAddress &address)
virtual IPAddress	receive (std::back_insert_iterator< std::vector< uint8_t >> it, const std::chrono::nanoseconds &timeout=std::chrono::nanoseconds::zero())

Protected Member Functions
std::ostream &	print_ (std::ostream &os) const final

Detailed Description

A unix UDP socket, listening on a port/address combination.

Definition at line 36 of file UnixUDPSocket.hpp.

Constructor & Destructor Documentation

UnixUDPSocket()

UnixUDPSocket::UnixUDPSocket	(	unsigned int	port,
		std::optional< IPAddress >	address = {},
		unsigned long	max_bitrate = 0,
		std::unique_ptr< UnixSyscalls >	syscalls = std::make_unique<UnixSyscalls>()
	)

Construct a UDP socket.

Parameters

port	The port number to listen on.
address	The address to listen on (the port portion of the address is ignored). The default is to listen on any address.
max_bitrate	The maximum number of bits per second to transmit on the UDP interface. The default is 0, which indicates no limit.
syscalls	The object to use for unix system calls. It is default constructed to the production implementation. This argument is only used for testing.

Exceptions

std::system_error

if a system call produces an error.

Definition at line 54 of file UnixUDPSocket.cpp.

~UnixUDPSocket()

UnixUDPSocket::~UnixUDPSocket ( )

virtual

The socket destructor.

Closes the underlying file descriptor of the UDP socket.

Definition at line 70 of file UnixUDPSocket.cpp.

Member Function Documentation

print_()

std::ostream & UnixUDPSocket::print_ ( std::ostream &  os ) const

finalprotectedvirtual

Print the UDP socket to the given output stream.

Parameters

os	The output stream to print to.

Returns

The output stream.

An example:

udp {
    port 14555;
    address 127.0.0.1;
    max_bitrate 262144;
}

Parameters

os	The output stream to print to.

Reimplemented from UDPSocket.

Definition at line 257 of file UnixUDPSocket.cpp.

receive() [1/2]

std::pair< std::vector< uint8_t >, IPAddress > UnixUDPSocket::receive ( const std::chrono::nanoseconds &  timeout = std::chrono::nanoseconds::zero() )

finalvirtual

Receive data on the socket.

Note

The timeout is not guaranteed to be up to nanosecond precision, the actual precision is up to the operating system's implementation but is guaranteed to have at least millisecond precision.

Parameters

timeout

How long to wait for data to arrive on the socket. The default is to not wait.

Returns

The data read from the socket and the IP address it was sent from.

Note

The timeout precision of this implementation is 1 millisecond.

Exceptions

std::system_error

if a system call produces an error.

Reimplemented from UDPSocket.

Definition at line 122 of file UnixUDPSocket.cpp.

receive() [2/2]

IPAddress UDPSocket::receive ( std::back_insert_iterator< std::vector< uint8_t >>  it, const std::chrono::nanoseconds &  timeout = std::chrono::nanoseconds::zero()  )

virtualinherited

Receive data on the socket.

Note

The timeout is not guaranteed to be up to nanosecond precision, the actual precision is up to the operating system's implementation but is guaranteed to have at least millisecond precision.

Parameters

it	A back insert iterator to read bytes into.
timeout	How long to wait for data to arrive on the socket. The default is to not wait.

Returns

The IP address the data was sent from, this is where a reply should be sent to.

Definition at line 97 of file UDPSocket.cpp.

References UDPSocket::receive().

Here is the call graph for this function:

send() [1/2]

void UnixUDPSocket::send ( const std::vector< uint8_t > &  data, const IPAddress &  address  )

finalvirtual

Send data to the given address using the socket.

Parameters

data	The bytes to send.
address	The IP address (with port number) to send the bytes to, using UDP.

Exceptions

PartialSendError

if it fails to write all the data it is given.

Reimplemented from UDPSocket.

Definition at line 81 of file UnixUDPSocket.cpp.

References IPAddress::address(), and IPAddress::port().

Here is the call graph for this function:

send() [2/2]

void UDPSocket::send ( std::vector< uint8_t >::const_iterator  first, std::vector< uint8_t >::const_iterator  last, const IPAddress &  address  )

virtualinherited

Send data to the given address using the socket.

Parameters

first	Iterator to first byte in range to send.
last	Iterator to one past the last byte to send.
address	The IP address (with port number) to send the bytes to, using UDP.

Definition at line 56 of file UDPSocket.cpp.

References UDPSocket::send().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• UnixUDPSocket.hpp
• UnixUDPSocket.cpp
