ConnectionFactory< C, AP, PQ > Class Template Reference

#include <ConnectionFactory.hpp>

Inheritance diagram for ConnectionFactory< C, AP, PQ >:

Collaboration diagram for ConnectionFactory< C, AP, PQ >:

Public Member Functions
	ConnectionFactory (std::shared_ptr< Filter > filter, bool mirror=false)
TEST_VIRTUAL	~ConnectionFactory ()=default
TEST_VIRTUAL std::unique_ptr< C >	get (std::string name="unknown")
TEST_VIRTUAL bool	wait_for_packet (const std::chrono::nanoseconds &timeout)

Detailed Description

template<class C = Connection, class AP = AddressPool<>, class PQ = PacketQueue>
class ConnectionFactory< C, AP, PQ >

A factory for making related connections that use a common semaphore.

Definition at line 36 of file ConnectionFactory.hpp.

Constructor & Destructor Documentation

ConnectionFactory()

template<class C , class AP , class PQ >

ConnectionFactory< C, AP, PQ >::ConnectionFactory	(	std::shared_ptr< Filter >	filter,
		bool	mirror = false
	)

Construct a connection factory.

Template Parameters

C	The Connection class (or derived class) to use.
AP	The AddressPool class (or derived class) to use.
PQ	The PacketQueue class (or derived class) to use, must accept a callback function in it's constructor.

Parameters

filter	The packet filter to use for determining whether and with what priority to add a packet to the queue for transmission. This will be given to each constructed Connection. Cannot be nullptr.
mirror	Set to true if all Connection's made by this factory are to be mirror connections. A mirror connection is one that will receive all packets, regardless of destination address. The default is false.

Exceptions

std::invalid_argument

if the given filter pointer is null.

Definition at line 67 of file ConnectionFactory.hpp.

~ConnectionFactory()

template<class C = Connection, class AP = AddressPool<>, class PQ = PacketQueue>

TEST_VIRTUAL ConnectionFactory< C, AP, PQ >::~ConnectionFactory ( )

default

Member Function Documentation

get()

template<class C , class AP , class PQ >

std::unique_ptr< C > ConnectionFactory< C, AP, PQ >::get

(

std::string

name = "unknown"

)

Construct and return a new connection.

This connection will share a common semaphore with all other connections made by this factory instance.

Parameters

name	The name of the new connection.

Returns

The new connection.

Definition at line 87 of file ConnectionFactory.hpp.

wait_for_packet()

template<class C , class AP , class PQ >

bool ConnectionFactory< C, AP, PQ >::wait_for_packet

(

const std::chrono::nanoseconds &

timeout

)

Wait for a packet to be available on any connection made by this factory.

Parameters

timeout

How long to block waiting for a packet. Set to 0s for non blocking.

Return values

true	There is a packet on at lest one of the connections created by this factory instance.
false	The wait timed out, there is no packet available on any of the connections created by this factory instance.

Definition at line 109 of file ConnectionFactory.hpp.

---

The documentation for this class was generated from the following file:

• ConnectionFactory.hpp
