Filter Class Reference

#include <Filter.hpp>

Collaboration diagram for Filter:

Public Member Functions
	Filter (const Filter &other)=default
	Filter (Filter &&other)=default
	Filter (Chain default_chain, bool accept_by_default=false)
TEST_VIRTUAL	~Filter ()=default
TEST_VIRTUAL std::pair< bool, int >	will_accept (const Packet &packet, const MAVAddress &address)
Filter &	operator= (const Filter &other)=default
Filter &	operator= (Filter &&other)=default

Friends
bool	operator== (const Filter &lhs, const Filter &rhs)
bool	operator!= (const Filter &lhs, const Filter &rhs)

Detailed Description

The filter used to determine whether to accept or reject a packet.

See also

Chain

Rule

If

Definition at line 38 of file Filter.hpp.

Constructor & Destructor Documentation

Filter() [1/3]

Filter::Filter ( const Filter &  other )

default

Copy constructor.

Parameters

other

Filter to copy from.

Filter() [2/3]

Filter::Filter ( Filter &&  other )

default

Move constructor.

Parameters

other

Filter to move from.

Filter() [3/3]

Filter::Filter	(	Chain	default_chain,
		bool	accept_by_default = false
	)

Construct a new packet filter.

Parameters

default_chain	The Chain that all filtering begins with.
accept_by_default	Whether to accept (true) or reject (false) packets that don't match any rules in the default chain or any chains called by the default chain. The default value is false and thus to reject unmatched packets.

Definition at line 36 of file Filter.cpp.

~Filter()

TEST_VIRTUAL Filter::~Filter ( )

default

Member Function Documentation

operator=() [1/2]

Filter& Filter::operator= ( const Filter &  other )

default

Assignment operator.

Parameters

other

Filter to copy from.

operator=() [2/2]

Filter& Filter::operator= ( Filter &&  other )

default

Assignment operator (by move semantics).

Parameters

other

Filter to move from.

will_accept()

std::pair< bool, int > Filter::will_accept	(	const Packet &	packet,
		const MAVAddress &	address
	)

Determine whether to accept or reject a packet/address combination.

Parameters

packet	The packet to determine whether to allow or not.
address	The address the packet will be sent out on if the action allows it.

Returns

A pair (tuple) with the first value being whether to accept the packet or not and the second being the priority to use when sending the packet. The second value is only defined if the first value is true (accept).

Definition at line 53 of file Filter.cpp.

References Action::ACCEPT, Chain::action(), Action::action(), Action::CONTINUE, Action::DEFAULT, Action::priority(), and Action::REJECT.

Here is the call graph for this function:

Friends And Related Function Documentation

operator!=

bool operator!= ( const Filter &  lhs, const Filter &  rhs  )

friend

Inequality comparison.

The default chain and default action are compared.

Parameters

lhs	The left hand side packet filter.
rhs	The right hand side packet filter.

Return values

true	if lhs is not the same as rhs.
false	if lhs is the same as rhs.

Definition at line 102 of file Filter.cpp.

operator==

bool operator== ( const Filter &  lhs, const Filter &  rhs  )

friend

Equality comparison.

The default chain and default action are compared.

Parameters

lhs	The left hand side packet filter.
rhs	The right hand side packet filter.

Return values

true	if lhs is the same as rhs.
false	if lhs is not the same as rhs.

Definition at line 85 of file Filter.cpp.

---

The documentation for this class was generated from the following files:

• Filter.hpp
• Filter.cpp
