Chain Class Reference

#include <Chain.hpp>

Collaboration diagram for Chain:

Public Member Functions
	Chain (const Chain &other)
	Chain (Chain &&other)=default
	Chain (std::string name_, std::vector< std::unique_ptr< Rule >> &&rules={})
TEST_VIRTUAL	~Chain ()=default
TEST_VIRTUAL Action	action (const Packet &packet, const MAVAddress &address)
void	append (std::unique_ptr< Rule > rule)
const std::string &	name () const
Chain &	operator= (const Chain &other)
Chain &	operator= (Chain &&other)=default

Friends
bool	operator== (const Chain &lhs, const Chain &rhs)
bool	operator!= (const Chain &lhs, const Chain &rhs)
std::ostream &	operator<< (std::ostream &os, const Chain &chain)

Detailed Description

A filter chain, containing a list of rules to check packets against.

Definition at line 37 of file Chain.hpp.

Constructor & Destructor Documentation

Chain() [1/3]

Chain::Chain

(

const Chain &

other

)

Copy constructor.

Parameters

other

Chain to copy from.

Definition at line 38 of file Chain.cpp.

References Rule::clone(), and rule.

Here is the call graph for this function:

Chain() [2/3]

Chain::Chain ( Chain &&  other )

default

Move constructor.

Parameters

other

Chain to move from.

Chain() [3/3]

Chain::Chain	(	std::string	name,
		std::vector< std::unique_ptr< Rule >> &&	rules = {}
	)

Construct a new filter chain.

Note

No rule in the chain may contain a GoTo or Call that would directly or indirectly result in returning to this chain.

Parameters

name	The name of the filter chain. This is only used when printing the chain. The name cannot contain whitespace.
rules	A vector of the rules used in the filter chain. This must be moved from since the vector is made up of std::unique_ptr's.

Exceptions

std::invalid_argument

if the name contains whitespace.

Definition at line 59 of file Chain.cpp.

~Chain()

TEST_VIRTUAL Chain::~Chain ( )

default

Member Function Documentation

action()

Action Chain::action	(	const Packet &	packet,
		const MAVAddress &	address
	)

Decide what to do with a Packet.

Determine what action to take with the given packet sent to the given address. The possible actions are documented in the Action class.

The filter chain will loop through all the rules and the first one that matches and returns something other than the continue Action will be taken as the result.

Note

An error will be thrown if any Call or GoTo rule matches that directly or indirectly loops back to this chain.

Parameters

packet	The packet to determine whether to allow or not.
address	The address the packet will be sent out on if the action allows it.

Returns

The action to take with the packet. If this is the accept Action object, it may also contain a priority for the packet.

Exceptions

RecursionError

if a rule loops back to this chain.

Definition at line 90 of file Chain.cpp.

References Rule::action(), Action::CONTINUE, Action::make_continue(), and rule.

Here is the call graph for this function:

Here is the caller graph for this function:

append()

void Chain::append

(

std::unique_ptr< Rule >

rule

)

Append a new rule to the filter chain.

Parameters

rule	A new filter rule to append to the chain.

Definition at line 116 of file Chain.cpp.

References rule.

Here is the caller graph for this function:

name()

const std::string & Chain::name

(

)

const

Return the name of the chain.

Note

This is only used when printing the chain.

Returns

The chain's name.

Definition at line 128 of file Chain.cpp.

operator=() [1/2]

Chain & Chain::operator=

(

const Chain &

other

)

Assignment operator.

Parameters

other

Chain to copy from.

Definition at line 138 of file Chain.cpp.

References Rule::clone(), and rule.

Here is the call graph for this function:

operator=() [2/2]

Chain& Chain::operator= ( Chain &&  other )

default

Assignment operator (by move semantics).

Parameters

other

Chain to move from.

Friends And Related Function Documentation

operator!=

bool operator!= ( const Chain &  lhs, const Chain &  rhs  )

friend

Inequality comparison.

Compares the chain name and each Rule in the chain.

Parameters

lhs	The left hand side action.
rhs	The right hand side action.

Return values

true	if lhs is not the same as rhs.
false	if lhs is the same as rhs.

Definition at line 200 of file Chain.cpp.

operator<<

std::ostream & operator<< ( std::ostream &  os, const Chain &  chain  )

friend

Print the given filter chain to to the given output stream.

An example is:

chain default {
    reject if HEARTBEAT from 10.10;
    accept with priority -3 if GPS_STATUS to 172.0/8;
    accept if GLOBAL_POSITION_INT to 172.0/8;
    goto ap-in with priority 3 if from 192.168;
    call ap-out if to 192.168;
    reject;
}

Parameters

os	The output stream to print to.
chain	The filter chain to print.

Returns

The output stream.

Definition at line 225 of file Chain.cpp.

operator==

bool operator== ( const Chain &  lhs, const Chain &  rhs  )

friend

Equality comparison.

Compares the chain name and each Rule in the chain.

Parameters

lhs	The left hand side filter chain.
rhs	The right hand side filter chain.

Return values

true	if lhs is the same as rhs.
false	if lhs is not the same as rhs.

Definition at line 163 of file Chain.cpp.

---

The documentation for this class was generated from the following files:

• Chain.hpp
• Chain.cpp
