#include <Action.hpp>

Collaboration diagram for Action:

Public Types
enum	Option { ACCEPT, REJECT, CONTINUE, DEFAULT }

Public Member Functions
	Action (const Action &other)=default

	Action (Action &&other)=default

Action::Option	action () const

void	priority (int priority)

int	priority () const

Action &	operator= (const Action &other)=default

Action &	operator= (Action &&other)=default

Static Public Member Functions
static Action	make_accept (std::optional< int > priority={})

static Action	make_reject ()

static Action	make_continue ()

static Action	make_default ()

Related Functions
(Note that these are not member functions.)
bool	operator== (const Action &lhs, const Action &rhs)

bool	operator!= (const Action &lhs, const Action &rhs)

std::ostream &	operator<< (std::ostream &os, const Action &action)

Detailed Description

An action that is to be taken with a packet.

This is used as a return value to determine what to do with a packet.

Definition at line 30 of file Action.hpp.

Member Enumeration Documentation

◆ Option

enum Action::Option

Possible actions.

Enumerator
ACCEPT	The packet has been accepted, possibly with priority.
REJECT	The packet has been rejected.
CONTINUE	Continue evaluating rules.
DEFAULT	Use the default rule.

Definition at line 35 of file Action.hpp.

Constructor & Destructor Documentation

◆ Action() [1/2]

Action::Action ( const Action & other )

default

Copy constructor.

Parameters

other Action to copy from.

Here is the caller graph for this function:

◆ Action() [2/2]

Action::Action ( Action && other )

default

Move constructor.

Parameters

other Action to move from.

Member Function Documentation

◆ action()

Action::Option Action::action ( ) const

Return the action that has been chosen.

Returns: The Action::Option enum associated with this action.

Definition at line 45 of file Action.cpp.

Here is the caller graph for this function:

◆ make_accept()

Action Action::make_accept ( std::optional< int > priority = {} )

static

Make a new action result with the Action::ACCEPT action.

An accept action indicates that the packet/address combination this action is the response to should be accepted without any further processing.

Parameters

priority The priority to accept the packet with. The default is to not apply a priority.

Returns: The new 'accept' action.

Definition at line 100 of file Action.cpp.

References ACCEPT, Action(), and priority().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ make_continue()

Action Action::make_continue ( )

static

Make a new action result with the Action::CONTINUE action.

A continue action indicates that filtering of the packet/address combination this action is the response should continue with the next Rule.

Returns: The new 'continue' action.

Definition at line 126 of file Action.cpp.

References Action(), and CONTINUE.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ make_default()

Action Action::make_default ( )

static

Make a new action result with the Action::DEFAULT action.

A default action indicates that the default action (defined in Filter) should be taken for the packet/address combination this action is the response to.

Returns: The new 'default' action.

Definition at line 140 of file Action.cpp.

References Action(), and DEFAULT.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ make_reject()

Action Action::make_reject ( )

static

Make a new action result with the Action::REJECT action.

A reject action indicates that the packet/address combination this action is the response to should be rejected without any further processing.

Returns: The new 'reject' action.

Definition at line 113 of file Action.cpp.

References Action(), and REJECT.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=() [1/2]

Action& Action::operator= ( const Action & other )

default

Assignment operator.

Parameters

other Action to copy from.

◆ operator=() [2/2]

Action& Action::operator= ( Action && other )

default

Assignment operator (by move semantics).

Parameters

other Action to move from.

◆ priority() [1/2]

void Action::priority ( int priority )

Set the priority of the action.

This only has an effect if the action is Action::ACCEPT and the priority has never been set before.

The default priority is 0. A higher priority will result in the packet being prioritized over other packets while a lower (negative) priority will de-prioritize the packet.

Parameters

priority The priority to apply to the accept action.

Definition at line 62 of file Action.cpp.

References ACCEPT, and priority().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ priority() [2/2]

int Action::priority ( ) const

Return the priority if it exists.

Returns: The priority of the action. This will always be 0 if the action is not Action::ACCEPT. It will also be 0 (the default priority) if the priority has never been set.

Definition at line 80 of file Action.cpp.

Here is the caller graph for this function:

Friends And Related Function Documentation

◆ operator!=()

bool operator!=	(	const Action &	lhs,
		const Action &	rhs
	)

Parameters

lhs	The left hand side action.
rhs	The right hand side action.

Return values

true	if `lhs` is not the same as rhs.
false	if `lhs` is the same as rhs.

Definition at line 168 of file Action.cpp.

References action(), and priority().

Here is the call graph for this function:

◆ operator<<()

std::ostream & operator<<	(	std::ostream &	os,
		const Action &	action
	)

Some examples are:

accept
accept with priority 3
reject
continue
default

Parameters

os	The output stream to print to.
action	The action result to print.

Returns: The output stream.

Definition at line 188 of file Action.cpp.

References ACCEPT, action(), CONTINUE, DEFAULT, priority(), and REJECT.

Here is the call graph for this function:

◆ operator==()

bool operator==	(	const Action &	lhs,
		const Action &	rhs
	)

Parameters

lhs	The left hand side action.
rhs	The right hand side action.

Return values

true	if `lhs` is the same as rhs.
false	if `lhs` is not the same as rhs.

Definition at line 154 of file Action.cpp.

References action(), and priority().

Here is the call graph for this function:
