#include <If.hpp>

Collaboration diagram for If:

Public Member Functions
	If (std::optional< unsigned long > id={}, std::optional< MAVSubnet > source={}, std::optional< MAVSubnet > dest={})

	If (const If &other)=default

	If (If &&other)=default

If &	type (unsigned long id)

If &	type (const std::string &name)

If &	from (MAVSubnet subnet)

If &	from (const std::string &subnet)

If &	to (MAVSubnet subnet)

If &	to (const std::string &subnet)

bool	check (const Packet &packet, const MAVAddress &address) const

If &	operator= (const If &other)=default

If &	operator= (If &&other)=default

Friends
bool	operator== (const If &lhs, const If &rhs)

bool	operator!= (const If &lhs, const If &rhs)

std::ostream &	operator<< (std::ostream &os, const If &if_)

Detailed Description

An if statement used to determine if a packet matches a rule.

This uses the type, source, and destination of a packet to determine if it matches.

Definition at line 35 of file If.hpp.

Constructor & Destructor Documentation

◆ If() [1/3]

If::If	(	std::optional< unsigned long >	id = `{}`,
		std::optional< MAVSubnet >	source = `{}`,
		std::optional< MAVSubnet >	dest = `{}`
	)

Construct an If statement.

The default is to allow any type of packet from any address to any address.

The type, to, and from methods can be used to apply conditions after construction. Some examples are:

If().type("PING").from("1.0/8").to("255.0");
If().type("HEARTBEAT").from("255.0/8");
If().type("SET_MODE").to("255.0/8");
If().from("255.0/8");

Parameters

id	The packet ID to match. If {} (std::nullopt) then any packet ID will match. The defaut is {}.
source	The subnet a source address must be in to match. If {} (std::nullopt) then any source address will match. The default is {}.
dest	The subnet a destination address must be in to match. If {} (std::nullopt) then any destination address will match. The default is {}.

Exceptions

std::invalid_argument if the given id is not valid.

Definition at line 49 of file If.cpp.

References type().

Here is the call graph for this function:

◆ If() [2/3]

If::If ( const If & other )

default

Copy constructor.

Parameters

other If to copy from.

◆ If() [3/3]

If::If ( If && other )

default

Move constructor.

Parameters

other If to move from.

Member Function Documentation

◆ check()

bool If::check	(	const Packet &	packet,
		const MAVAddress &	address
	)		const

Check whether a Packet and MAVAddress combination matches.

Parameters

packet	The packet to check for a match.
address	The address the packet is to be sent to.

Return values

true	If the packet matches the type, source subnet (by MAVSubnet::contains), and destination subnet (by MAVSubnet::contains) of the if statement.
false	If any of the packet type, source subnet, or destination subnet does not match.

Definition at line 160 of file If.cpp.

References Packet::id(), and Packet::source().

Here is the call graph for this function:

◆ from() [1/2]

If & If::from ( MAVSubnet subnet )

Set subnet for source address matching using MAVSubnet.

Parameters

subnet The subnet used for source address matching.

Returns: A reference to itself.

See also: from(const std::string &subnet)

Definition at line 98 of file If.cpp.

Here is the caller graph for this function:

◆ from() [2/2]

If & If::from ( const std::string & subnet )

Set subnet for source address matching by string.

See MAVSubnet::MAVSubnet(std::string address) for the acceptable formats and possible errors.

Parameters

subnet The subnet used for source address matching.

Returns: A reference to itself.

See also: from(MAVSubnet subnet)

Definition at line 114 of file If.cpp.

◆ operator=() [1/2]

If& If::operator= ( const If & other )

default

Assignment operator.

Parameters

other If to copy from.

◆ operator=() [2/2]

If& If::operator= ( If && other )

default

Assignment operator (by move semantics).

Parameters

other If to move from.

◆ to() [1/2]

If & If::to ( MAVSubnet subnet )

Set subnet for destination address matching using MAVSubnet.

Parameters

subnet The subnet used for destination address matching.

Returns: A reference to itself.

See also: to(const std::string &subnet)

Definition at line 127 of file If.cpp.

Here is the caller graph for this function:

◆ to() [2/2]

If & If::to ( const std::string & subnet )

Set subnet for destination address matching by string.

See MAVSubnet::MAVSubnet(std::string address) for the acceptable formats and possible errors.

Parameters

subnet The subnet used for destination address matching.

Returns: A reference to itself.

See also: to(MAVSubnet subnet)

Definition at line 143 of file If.cpp.

◆ type() [1/2]

If & If::type ( unsigned long id )

Set the packet type to match, by ID.

Parameters

id	The packet ID to match.

Returns: A reference to itself.

Exceptions

std::invalid_argument if the given id is not valid.

See also: type(const std::string &name)

Definition at line 69 of file If.cpp.

References mavlink::id(), and mavlink::name().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ type() [2/2]

If & If::type ( const std::string & name )

Set the packet type to match, by name.

Parameters

name	The packet name to match.

Returns: A reference to itself.

Exceptions

std::invalid_argument if the given message name is not valid.

See also: type(unsigned long id)

Definition at line 85 of file If.cpp.

References mavlink::id(), and mavlink::name().

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator!=

bool operator!=	(	const If &	lhs,
		const If &	rhs
	)

friend

Inequality comparison.

Parameters

lhs	The left hand side if statement.
rhs	The right hand side if statement.

Return values

true	if `lhs` and `rhs` are not the same.
false	if `lhs` and `rhs` are the same.

Definition at line 209 of file If.cpp.

◆ operator<<

std::ostream& operator<<	(	std::ostream &	os,
		const If &	if_
	)

friend

Print the If statement to the given output stream.

Some examples are:

if PING from 1.0/8 to 255.0
if HEARTBEAT from 255.0/8
if SET_MODE to 255.0
if from 255.0/8

Definition at line 224 of file If.cpp.

◆ operator==

bool operator==	(	const If &	lhs,
		const If &	rhs
	)

friend

Equality comparison.

Parameters

lhs	The left hand side if statement.
rhs	The right hand side if statement.

Return values

true	if `lhs` and `rhs` are the same.
false	if `lhs` and `rhs` are not the same.

Definition at line 194 of file If.cpp.

The documentation for this class was generated from the following files:
