UDPInterface Class Reference

#include <UDPInterface.hpp>

Inheritance diagram for UDPInterface:

Collaboration diagram for UDPInterface:

Public Member Functions
	UDPInterface (std::unique_ptr< UDPSocket > socket, std::shared_ptr< ConnectionPool > connection_pool, std::unique_ptr< ConnectionFactory<>> connection_factory)
	~UDPInterface ()=default
void	send_packet (const std::chrono::nanoseconds &timeout) final
void	receive_packet (const std::chrono::nanoseconds &timeout) final

Protected Member Functions
std::ostream &	print_ (std::ostream &os) const final

Detailed Description

A UDP (User Datagram Protocol) interface.

An interface (for sending and receiving packets) implementing the user datagram protocol.

Definition at line 40 of file UDPInterface.hpp.

Constructor & Destructor Documentation

UDPInterface()

UDPInterface::UDPInterface	(	std::unique_ptr< UDPSocket >	socket,
		std::shared_ptr< ConnectionPool >	connection_pool,
		std::unique_ptr< ConnectionFactory<>>	connection_factory
	)

Construct a UDP interface using a given socket.

Parameters

socket	The UDP socket to communicate over.
connection_pool	The connection pool to use for sending packets and to register new connections with.
connection_factory	The connection factory to use for constructing new connections when an outside connection is made.

Exceptions

std::invalid_argument	if the serial port device pointer is null.
std::invalid_argument	if the connection_pool pointer is null.
std::invalid_argument	if the connection_factory pointer is null.

Definition at line 71 of file UDPInterface.cpp.

~UDPInterface()

UDPInterface::~UDPInterface ( )

default

Member Function Documentation

print_()

std::ostream & UDPInterface::print_ ( std::ostream &  os ) const

finalprotectedvirtual

Print the interface to the given output stream.

Parameters

os	The output stream to print to.

Returns

The output stream.

Example:

udp {
    port 14500;
    address 127.0.0.1;
}

Implements Interface.

Definition at line 180 of file UDPInterface.cpp.

receive_packet()

void UDPInterface::receive_packet ( const std::chrono::nanoseconds &  timeout )

finalvirtual

Receive a packet on the interface.

Parameters

timeout

The maximum amount of time to wait for incoming data.

Receives up to one UDP packet worth of data and parses it into MAVLink packets before passing these packets onto the connection pool. Will wait up to timeout for a UDP packet to be received.

Implements Interface.

Definition at line 138 of file UDPInterface.cpp.

References PacketParser::clear(), and PacketParser::parse_byte().

Here is the call graph for this function:

send_packet()

void UDPInterface::send_packet ( const std::chrono::nanoseconds &  timeout )

finalvirtual

Send a packet from one of the interface's connections.

Note

Which connection to take this packet from is not defined but it must not starve any one of the Interface's connections.

Parameters

timeout

The maximum amount of time to wait for a packet to be available for sending.

Sends up to one packet from each connection, belonging to the interface, over the UDP socket.

Implements Interface.

Definition at line 103 of file UDPInterface.cpp.

---

The documentation for this class was generated from the following files:

• UDPInterface.hpp
• UDPInterface.cpp
