Accept Class Reference

#include <Accept.hpp>

Inheritance diagram for Accept:

Collaboration diagram for Accept:

Public Member Functions
	Accept (std::optional< If > condition={})
	Accept (int priority, std::optional< If > condition={})
virtual Action	action (const Packet &packet, const MAVAddress &address) const
virtual std::unique_ptr< Rule >	clone () const
virtual bool	operator== (const Rule &other) const
virtual bool	operator!= (const Rule &other) const

Protected Member Functions
virtual std::ostream &	print_ (std::ostream &os) const

Protected Attributes
std::optional< If >	condition_

Detailed Description

Rule to accept a packet, optionally with a priority.

Definition at line 35 of file Accept.hpp.

Constructor & Destructor Documentation

Accept() [1/2]

Accept::Accept

(

std::optional< If >

condition = {}

)

Construct an accept rule, without a priority.

An accept rule is used to accept packet/address combinations that match the condition of the rule.

Parameters

condition

The condition used to determine the rule matches a particular packet/address combination given to the action method. The default is {} which indicates the rule matches any packet/address combination.

See also

action

Definition at line 42 of file Accept.cpp.

Accept() [2/2]

Accept::Accept	(	int	priority,
		std::optional< If >	condition = {}
	)

Construct an accept rule, with a priority.

An accept rule is used to accept packet/address combinations that match the condition of the rule.

Parameters

condition	The condition used to determine the rule matches a particular packet/address combination given to the action method. The default is {} which indicates the rule matches any packet/address combination.
priority	The priority to accept packets with. A higher number is more important and will be routed first.

See also

action

Definition at line 61 of file Accept.cpp.

Member Function Documentation

action()

Action Accept::action ( const Packet &  packet, const MAVAddress &  address  ) const

virtual

Decide what to do with a Packet.

Determine what action to take with the given packet sent to the given address. The possible actions are documented in the Action class. The continue object is always returned if the condition was set and does not match the packet/address combination.

Parameters

packet	The packet to determine whether to allow or not.
address	The address the packet will be sent out on if the action dictates it.

Returns

The action to take with the packet. If this is the accept object, it may also contain a priority for the packet.

If the condition has not been set or it matches the given packet/address combination then it will return the accept Action object (with optional priority), otherwise it will return the continue Action object.

Implements Rule.

Definition at line 99 of file Accept.cpp.

References Rule::condition_, Action::make_accept(), and Action::make_continue().

Here is the call graph for this function:

clone()

std::unique_ptr< Rule > Accept::clone ( ) const

virtual

Return a copy of the Rule polymorphically.

This allows Rule's to be copied without knowing the derived type.

Returns

A pointer to a new object with base type Rule which is an exact copy of this one.

Implements Rule.

Definition at line 111 of file Accept.cpp.

References Rule::condition_.

operator!=()

bool Accept::operator!= ( const Rule &  other ) const

virtual

Inequality comparison.

Compares the type of the Rule and the condition (If) if set.

Parameters

other

The other rule to compare this to.

Return values

true	if this rule is not the same as other.
false	if this rule is the same as other.

Compares the priority (if set) associated with the rule as well.

Implements Rule.

Definition at line 138 of file Accept.cpp.

References Rule::condition_.

operator==()

bool Accept::operator== ( const Rule &  other ) const

virtual

Equality comparison.

Compares the type of the Rule and the condition (If) if set.

Parameters

other

The other rule to compare this to.

Return values

true	if this rule is the same as other.
false	if this rule is not the same as other.

Compares the priority (if set) associated with the rule as well.

Implements Rule.

Definition at line 126 of file Accept.cpp.

References Rule::condition_.

print_()

std::ostream & Accept::print_ ( std::ostream &  os ) const

protectedvirtual

Print the rule to the given output stream.

Parameters

os	The output stream to print to.

Returns

The output stream.

Prints "reject <Priority> <If Statement>" where the priority and if statement are only printed if the priority or condition is set, respectively.

Parameters

os	The output stream to print to.

Implements Rule.

Definition at line 75 of file Accept.cpp.

References Rule::condition_.

Member Data Documentation

condition_

std::optional<If> Rule::condition_

protectedinherited

Definition at line 91 of file Rule.hpp.

---

The documentation for this class was generated from the following files:

• Accept.hpp
• Accept.cpp
