#include <ConfigParser.hpp>

Collaboration diagram for ConfigParser:

Public Member Functions
	ConfigParser (std::string filename)

	ConfigParser (const ConfigParser &other)=delete

	ConfigParser (ConfigParser &&other)=delete

std::unique_ptr< App >	make_app ()

ConfigParser &	operator= (const ConfigParser &other)=delete

ConfigParser &	operator= (ConfigParser &&other)=delete

Protected Attributes
tao::pegtl::read_input	in_

std::unique_ptr< config::parse_tree::node >	root_

Friends
std::ostream &	operator<< (std::ostream &os, const ConfigParser &config_parser)

Related Functions
(Note that these are not member functions.)
std::map< std::string, std::shared_ptr< Chain > >	init_chains (const config::parse_tree::node &root)

std::unique_ptr< Rule >	parse_action (const config::parse_tree::node &root, std::optional< int > priority, std::optional< If > condition, const std::map< std::string, std::shared_ptr< Chain >> &chains)

void	parse_chain (Chain &chain, const config::parse_tree::node &root, const std::map< std::string, std::shared_ptr< Chain >> &chains)

If	parse_condition (const config::parse_tree::node &root)

std::unique_ptr< Filter >	parse_filter (const config::parse_tree::node &root)

std::vector< std::unique_ptr< Interface > >	parse_interfaces (const config::parse_tree::node &root, std::unique_ptr< Filter > filter)

std::unique_ptr< SerialInterface >	parse_serial (const config::parse_tree::node &root, std::shared_ptr< Filter > filter, std::shared_ptr< ConnectionPool > pool)

std::unique_ptr< UDPInterface >	parse_udp (const config::parse_tree::node &root, std::shared_ptr< Filter > filter, std::shared_ptr< ConnectionPool > pool)

Detailed Description

Configuration file parser.

Used to parse a configuration file and create an instance of the mavtables application.

Definition at line 74 of file ConfigParser.hpp.

Constructor & Destructor Documentation

◆ ConfigParser() [1/3]

ConfigParser::ConfigParser ( std::string filename )

Construct a configuration parser from a file.

Parameters

filename The path of the configuration file to parse.

Exceptions

std::runtime_error if the configuration file cannot be parsed.

Definition at line 443 of file ConfigParser.cpp.

References in_, config::parse(), and root_.

Here is the call graph for this function:

◆ ConfigParser() [2/3]

ConfigParser::ConfigParser ( const ConfigParser & other )

delete

◆ ConfigParser() [3/3]

ConfigParser::ConfigParser ( ConfigParser && other )

delete

Member Function Documentation

◆ make_app()

std::unique_ptr< App > ConfigParser::make_app ( )

Build a mavtables application from the AST contained by the parser.

Returns: A mavtables application.

Definition at line 464 of file ConfigParser.cpp.

References parse_filter(), parse_interfaces(), and root_.

Here is the call graph for this function:

◆ operator=() [1/2]

ConfigParser& ConfigParser::operator= ( const ConfigParser & other )

delete

◆ operator=() [2/2]

ConfigParser& ConfigParser::operator= ( ConfigParser && other )

delete

Friends And Related Function Documentation

◆ init_chains()

std::map< std::string, std::shared_ptr< Chain > > init_chains ( const config::parse_tree::node & root )

Parameters

root	Root of configuration AST.

Returns: Map of chain names to chains.

Definition at line 54 of file ConfigParser.cpp.

Here is the caller graph for this function:

◆ operator<<

std::ostream & operator<<	(	std::ostream &	os,
		const ConfigParser &	config_parser
	)

friend

Print the configuration settings to the given output stream.

An example (that of test/mavtables.conf) is:

===== test/mavtables.conf =====
:001:  default_action
:001:  |  accept
:004:  udp
:005:  |  port 14500
:006:  |  address 127.0.0.1
:007:  |  max_bitrate 8388608
:011:  serial
:012:  |  device ./ttyS0
:013:  |  baudrate 115200
:014:  |  flow_control yes
:015:  |  preload 1.1
:016:  |  preload 62.34
:020:  chain default
:022:  |  call some_chain10
:022:  |  |  condition
:022:  |  |  |  source 127.1
:022:  |  |  |  dest 192.0
:023:  |  reject
:027:  chain some_chain10
:029:  |  accept
:029:  |  |  priority 99
:029:  |  |  condition
:029:  |  |  |  dest 192.0
:030:  |  accept
:030:  |  |  condition
:030:  |  |  |  packet_type PING
:031:  |  accept

Parameters

os	The output stream to print to.
config_parser	The configuration parser to print.

Returns: The output stream.

Definition at line 512 of file ConfigParser.cpp.

◆ parse_action()

std::unique_ptr< Rule > parse_action	(	const config::parse_tree::node &	root,
		std::optional< int >	priority,
		std::optional< If >	condition,
		const std::map< std::string, std::shared_ptr< Chain >> &	chains
	)

Parameters

root	AST action node.
priority	The priority to use when constructing the action. No priority if {}. If the AST node is a reject action the priority will be ignored.
condition	The condition to use when constructing the action.
chains	Map of chain names to chains for call and goto actions.

Returns: The action (or rule) parsed from the given AST node, priority, and condition.

Exceptions

std::invalid_argument	if the action attempts to `call` or `goto` the default chain.
std::runtime_error	if the action is not one of `accept`, `reject`, `call`, or `goto`.

Definition at line 92 of file ConfigParser.cpp.

Here is the caller graph for this function:

◆ parse_chain()

void parse_chain	(	Chain &	chain,
		const config::parse_tree::node &	root,
		const std::map< std::string, std::shared_ptr< Chain >> &	chains
	)

Parameters

chain	Chain to add rules to.
root	AST chain node containing rules.
chains	Map of chain names to chains for call and goto actions.

Definition at line 176 of file ConfigParser.cpp.

References Chain::append(), parse_action(), and parse_condition().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parse_condition()

If parse_condition ( const config::parse_tree::node & root )

Parameters

root	AST conditional node.

Returns: The conditional constructed from the given AST node.

Definition at line 216 of file ConfigParser.cpp.

References If::from(), If::to(), and If::type().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parse_filter()

std::unique_ptr< Filter > parse_filter ( const config::parse_tree::node & root )

Parameters

root	Root of configuration AST.

Returns: The Filter parsed from the AST.

Definition at line 250 of file ConfigParser.cpp.

References init_chains(), and parse_chain().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parse_interfaces()

std::vector< std::unique_ptr< Interface > > parse_interfaces	(	const config::parse_tree::node &	root,
		std::unique_ptr< Filter >	filter
	)

Parameters

root	The root of the AST to create Interface's from.
filter	The packet Filter to use for the interfaces.

Returns: A vector of UDP and serial port interfaces.

Definition at line 292 of file ConfigParser.cpp.

References parse_serial(), and parse_udp().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parse_serial()

std::unique_ptr< SerialInterface > parse_serial	(	const config::parse_tree::node &	root,
		std::shared_ptr< Filter >	filter,
		std::shared_ptr< ConnectionPool >	pool
	)

Parameters

root	The serial port node to parse.
filter	The Filter to use for the SerialInterface.
pool	The connection pool to add the interface's connection to.

Returns: The serial port interface parsed from the AST and using the given filter and connection pool.

Exceptions

std::invalid_argument if the device string is missing.

Definition at line 330 of file ConfigParser.cpp.

References SerialPort::DEFAULT, SerialPort::FLOW_CONTROL, and to_lower().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parse_udp()

std::unique_ptr< UDPInterface > parse_udp	(	const config::parse_tree::node &	root,
		std::shared_ptr< Filter >	filter,
		std::shared_ptr< ConnectionPool >	pool
	)

Parameters

root	The UDP node to parse.
filter	The Filter to use for the UDPInterface.
pool	The connection pool to add the interface's connections to.

Returns: The UDP interface parsed from the AST and using the given filter and connection pool.

Definition at line 400 of file ConfigParser.cpp.

Here is the caller graph for this function:

Member Data Documentation

◆ in_

tao::pegtl::read_input ConfigParser::in_

protected

Definition at line 88 of file ConfigParser.hpp.

◆ root_

std::unique_ptr<config::parse_tree::node> ConfigParser::root_

protected

Definition at line 89 of file ConfigParser.hpp.

The documentation for this class was generated from the following files:
